Commercial Range


Commercial Series Windows & Doors

The range of Commercial Windows & Doors by Fairview will complement any of the Commercial Façade or Curtain Wall Façade Suite options.

They are easily integrated into the suite from a fabrication and installation perspective while also continuing the consistent ‘Commercial’ look and feel.

Benefits

Our expansive range of Commercial Windows and Doors utilise Italian designed high performance EPDM (ethylene propylene diene monomer) rubber to seal every joint where air and water leakage could occur.

These seals have been tested for water penetration resistance at wind speeds of approximately 145km/h, triple the performance of normal seals.

Glazing Options

The minimum glass thickness required is 4mm for single glazing and the maximum double-glazing unit is 28mm.

Testing

The Commercial Series has been tested and complies with NZS 4211 and AS 2047. This compliance is the result of thorough testing, quality design and strict quality control in manufacturing. Test Certificates are available upon request.

Design Loads

The Commercial Series achieves the relevant standards serviceability wind pressure, ultimate wind pressure and water pressure requirements.



Fairview Commercial 65

Range of Unitised Curtainwall Systems for multi-Storey Buildings.

Ideal Applications

- High Rise Commercial Applications
- Office Towers
- Apartments
- Hotels
- Stadiums
- Community Facilities

Features and Benefits

- Fully Unitised System
- Tested to NZS 4211 and AS 2047
- Glazing typically from 4mm Single Glazed up to 28mm Double Glazed
- Two piece seismic channel and seismic sill tray available



Fairview Commercial 50

Versatile & extensive Commercial Suite, For modern full height commercial joinery. Front/Centre/Rear Glazed options available.

Ideal Applications

- Retail
- Office Buildings
- Apartments
- Industrial Buildings
- Hotels & Motels
- Schools

Features and Benefits

- 75 | 100 | 125 | 150mm Frame options.
- 3 glass positions available: Front, central, Rear glazed options.
- Mullions can be captive/expressed, or structurally glazed.
- Two piece Split Mullion, One Piece Transom System.
- Tested to NZS 4211 and AS 2047
- Glazing from 4mm Single Glazed up to 28mm Double Glazed.
- Two piece seismic channel and seismic sill tray available.




Gallery




Your new view awaits

Contact us today for a more information
